Product Details:
|
High Light: | dvr h 264 digital video recorder,h.264 network digital video recorder |
---|
Quick Detail:
1. Model Number: DVR-3504
2. Brand Name: ZHIBOSEN
3. Type: DVR
4. Channel: 4 channel
5. Video input: 4 channel BNC
6. Audio input: 4 channel
7. HDD: Support 1 pcs 3T SATA
8. USB: 2 pcs USB2.0
9. Video connect:VGA/HDMI
10. Place of Origin: Guangdong China
11. Gross Weight: 2kg
12. Package Size: 255x225x45mm
Description:
1. Through cloud services, a variety of network penetration easy step you can achieve remote monitoring, which abandoned the various complicated network setup, simple, very convenient.
2. Compression algorithm upgrade to H.264 High Profile, advanced space-time filtering technology to stream representing a decrease of more than 30%
3. Full real-time video, support for full-time four-way D1,2 Road D1 + 6-channel CIF real-time, 16-channel CIF real-time, full real-time multi-channel synchronous playback.
4. Have two kinds of main and auxiliary stream while encoding, main stream local storage, ensuring high-definition image quality; auxiliary stream real-time network transmission, easy to solve bandwidth bottlenecks.
5. Support all types of mobile monitoring (iPhone, Windows Mobile, BlackBerry, Symbian, Android)
6. Supports multiple web browsers (IE, Chrome, Firefox, Safari).
7. Support 2 USB2.0 interface, stability, achieve USB mouse, backup, burn, upgrades and other operations.
8. Imitation Vista interface, similar to the WINDOWS operating style, powerful mouse right-click menu function, so surprisingly easy to get started.
9. Support TV, VGA and HDMI output simultaneously, including VGA and HDMI support 1024 * 768 Full HD output, to overturn the traditional display monitor.
10. Powerful network services (support DHCP, PPPOE, DNS, DDNS, EMAIL, IP search, etc.), perfect matching (WEB, Client, SDK), easy to achieve interoperability.
11. Support 3322 (Greek network), dyndns, oray (peanut shells), myq-see, such as Domain Name Service.
12. Twenty languages (English, Finnish, French, German, Greek, Italian, Japanese, Polish, Portuguese, Russian, Spanish, Thai, Chinese, Traditional Chinese, Turkish), breaking national boundaries. Flexible display, free replacement boot interface.
Applications:
Applies to family, community, roads, warehouses, underground parking, bar, schools, factories, companies, police stations, banks and other institutions.
Specifications :
Parameter | ||
System | Main processor | Industrial-grade embedded microcontroller platform Huawei Hass |
Operating System | Embedded LINUX operating system | |
System Resources | While multi-channel video, multi-channel auxiliary stream, multi-channel playback, multi-channel network operation, USB backup | |
Interface | Operator Interface | 16-bit true color graphical menu interface, support mouse, remote control, key operation |
Screen display | Quarter of the screen | |
Video | Video Standard | PAL (625 lines, 50 fields / s); NTSC (525 lines, 60 fields / s) |
Image Coding | H.264 (High Profile) | |
Monitoring quality | Monitor: D1, VGA, HDMI: 1024 * 768 | |
Playback quality | D1 / HD1 / CIF / QCIF | |
Encoding capabilities | 4 channel D1 real time | |
Decoding capability | 2 channel D1 real time | |
Motion Detection | Each screen can be set to 192 (16 * 12) detection areas; multi-level sensitivity can be set | |
(Only local channels) | ||
Audio | Audio Compression | G.711A |
Voice Intercom | Stand by | |
Recording and Playback | Video mode | Manual> Alarm> Motion Detection> Schedule |
Local Playback | Any large ones simultaneous playback | |
(1-4) | ||
Video Search | Time search, calendar search, event search, channel retrieval | |
Storage and backup | Videos take up hard disk space | Video CIF: 4 ~ 5G / day * Channel D1: 8 ~ 10G / day * channel |
Audio 691.2M / day * channel | ||
Recordings are saved | The hard drive, network | |
Backup | Network backup, U disk, USB mobile hard disk | |
Interface | Video Input | 4 BNC |
Video Output | Support a road BNC, 1 channel VGA, 1 channel HDMI output simultaneously | |
Audio Input | 4 RCA | |
Audio output | 1 channel RCA | |
Alarm Input | No | |
Alarm output | No | |
Network Interface | 1 RJ45 10M / 100M adaptive Ethernet port | |
Control Interface | An RS485 interface, support 18 kinds of PTZ protocol | |
USB interface | Two USB ports | |
Hard disk interface | A SATA interface (maximum support each 4T) | |
Other | Power source | 12V / 2A |
Size | 255mm (length) * 225mm (W) * 45mm (H) |
Competitive advantages:
good price, reliable quality, guarantee of delivery, best services
