Product Details:
Payment & Shipping Terms:
|
High Light: | dvr h 264 digital video recorder,network digital video recorder |
---|
Quick Detail:
1. Model Number: DVR-3508
2. Brand Name: ZHIBOSEN
3. Type: DVR
4. Channel: 8 channel
5. Video input: 8 channel BNC
6. Audio input: 4 channel
7. HDD: Support 1 pcs 3T SATA
8. USB: 2 pcs USB2.0
9. Video connect:VGA/HDMI
10. Place of Origin: Guangdong China
11. Gross Weight: 2.2kg
12. Package Size: 255x225x45mm
Description:
1. ONVIF standard protocol Onvif agreement with standard: support onvif agreement with IPC front butt, but also with support onvif protocol client docking.
2. Step Internet Step on the Internet: abandon all kinds of complicated settings, through cloud services, a variety of network penetration easy step to achieve remote monitoring.
3. Compression Compression algorithm ideal: compression algorithm upgrade to H.264 Main Profile, advanced space-time filtering technology to stream representing a decrease of more than 30%
4. Playback quality Playback quality: full real-time synchronous decoding playback.
5. Video access Video access: have 8 1080P, a variety of storage 8 720P, 16-channel D1 and so on.
6. Phone monitoring Mobite monitor: Support various types of mobile monitoring (iPhone, Windows Mobile, BlackBerry, Symbian, Android)
7. Display Display: Support TV, HD VGA, HDMI HD output simultaneously, VGA, HDMI support 1080P HD output, true HD resolution output leading technology trends
8. Operation Interface Operation interface: Similar WINDOWS operating style, powerful mouse right-click menu function, so surprisingly easy to get started
9. Network Technology Network: Powerful network services (support DHCP, PPPOE, FTP, DNS, DDNS, NTP, UPNP, EMAILl, IP permissions, IP searches, Alarm Center, etc.), perfect (WEB, Client, SDK), easy to achieve interoperability
10. Browser Browsers: supports multiple web browser (ie, chrome, firefox, safari)
11. Remote Access Remote Access: own domain name services (ARSP), a key to enable remote monitoring, so that monitoring becomes easy and enjoyable. While providing 3322 (Greek network), dyndns, oray (peanut shells), myq-see, such as Domain Name Service.
12. Device Interface Device port: supports 1/2 SATA interfaces, can be accessed by 1/2 4T hard drive, two USB2.0 interface, stability, USB mouse, backup, burning, upgrading operations
13. Other Others: perfect protection circuit, unique triple watchdog function, ensure that the equipment never crash; has a unique black box technology, can monitor the whole process equipment, greatly reduce maintenance costs
Applications:
Applies to family, community, roads, warehouses, underground parking, bar, schools, factories, companies, police stations, banks and other institutions.
Specifications :
Interface | Main processor | Industrial grade embedded micro-controller chip Hi3520A Huawei Hass |
Operating system | Embedded LINUX operating system | |
System Resources | Simultaneous multi-channel real-time video, multi-channel real-time playback, multi-channel operation over the network, USB backup | |
Video | Interface | 16-bit true color graphical menu interface and mouse support |
Display | 1/4/9 screen | |
Video Standard | PAL (625 lines, 50 fields / s); NTSC (525 lines, 60 fields / s) | |
Image decoding | H.264 (Main Profile) | |
Monitoring quality | Monitor: D1; VGA, HDMI: High Definition | |
(1920 * 1080, 1280 * 720,1440 * 900, 1280 * 1024, 1024 * 768, 800 * 600) | ||
Playback quality | 1080P/720P/D1 | |
Decoding capability | One-way real-1080P | |
Motion Detection | Each screen can be set to 192 (16 * 12) detection areas; multi-level sensitivity can be set | |
(Only local channels) | ||
Audio frequency | Audio Compression | G.711A |
Recording and Playback | Language Talkback | Not supported |
Recording mode | Manual> Alarm> Motion Detection> Timing | |
Local Playback | 1 channel playback | |
Storage and backup | Video Search | Time searching, calendar, event search, channel search |
Interface | Each hard disk space occupied | Video: CIF 4 ~ 5G / day * channel, D1 8 ~ 10G / day * channel; |
Audio: 691.2M / day * channel | ||
Recordings are saved | The hard drive, network | |
Backup | Network backup, USB mobile hard disk, USB burner, SATA burner | |
Video access mode | 8 1080P / 8 channel D1 access road 720P/16 storage | |
Video Output | 1 channel BNC (1.0Vp-p, 75Ω), 1-way VGA, 1 HDMI output path | |
Audio Input | No | |
Audio Output | 1 channel RCA (200-3000mV, 5KΩ) | |
Network Interface | RJ45 10M/100M adaptive Ethernet port | |
PTZ control | An RS485 interface, support 18 kinds of PTZ protocol | |
USB Interface | 2 USB2.0 Interface | |
Other | Hard disk interface | 1/2 SATA interfaces, can be accessed by 1/2 4T HDD |
Power supply | 12V/3A | |
Power Consumption | <10W (without hard drive) | |
Operating Temperature | 0 ℃ - +55 ℃ | |
Humidity | 10% -90% | |
Atm | 86kpa-106kpa |
Competitive advantages:
good price, reliable quality, guarantee of delivery, best services
