High Light: | outdoor dome camera,wireless internet surveillance camera |
---|
1. M-JPEG ; CMOS .
2. 3x Optical Zoom ; IR-CUT.
3. Two-way audio; MSN server; Free Factory DDNS.
4. PT[Pan/Tilt] Vertically 90°, Horizontally 330°.
5. Image Frame Rate:Max. 30fps for 640x480.
6.Image Sensor:300K Pixels CMOS Sensor.
7. Nightvision: 12 LED lights ( Range: 10-15m ).
8. Support wireless network (Wi-Fi/ 802.11/b/g ).
9. Motion detection, email alert, FTP upload.
10. Iphone, 3G phone, Smartphone supported.
11. Multi-language, Firefox, Safari, Google browser .
Model |
BS-09BHE |
|
Image Sensor |
Image sensor |
1/5" Color CMOS Sensor |
|
Display |
640 x 480 (300K Pixels) |
|
Lens |
f:3.6mm, F:2.4 (IR Lens) |
|
Mini Illumination |
0.5 Lux |
Lens |
Lens Type |
Glass Lens |
|
Viewing Angle |
60 Degree |
Audio |
Microphone |
Audio of two way |
Domain name |
Server |
MSN server/ DDNS server |
Video |
Image Compression |
M-JPEG |
|
Image Frame Rate |
15 FPS(VGA),30FPS(QVGA) |
|
Resolution |
640 x 480(VGA), 320 x 240(QVGA) |
|
Flip Mirror Images |
Vertical / Horizontal |
|
Mode |
50Hz, 60Hz or Outdoor |
|
Video Parameters |
Brightness, Contrast |
Communication |
Ethernet |
One 10/100Mbps RJ-45 |
|
Supported Protocol |
HTTP/DHCP/IP/TCP/UDP/FTP/SMTP/DDNS/PPPoE/UPnP |
|
Mobile phone Monitor |
Support iPhone/iPad/3G Phone/Smartphone |
|
Wireless Standard |
IEEE 802.11b/g |
|
Wireless Standard |
802.11b:11Mbps (max.) 802.11g: 54Mbps (max.) |
|
Wireless Security |
64/128-bitWEP Encryption |
Physical |
Pan/Tilt Angle |
Horizontal:330° & Vertical: 90° / 3X Optical Zoom |
|
Infrared Light |
12 IR LEDs, Night visibility up to 15 Meters |
|
Product Size |
95(L)*100(W) *125(H)mm |
|
652gpcs (packing size:196*165*123mm) |
|
|
306.7g/pcs (only product) |
|
Power |
DC 5V/2.5A 1.8 meter |
|
|
Power Consumption |
5 Watts |
Environment |
Operate Temper |
0°~ 55°C (14°F~122°F) |
|
Operating Humidity |
20% ~ 85% non-condensing |
|
Storage Temper |
-10°C ~ 60° (14°F ~140°F) |
|
Storage Humidity |
0% ~ 90% non-condensing |
PC Requirements |
CPU |
2.0GHZ or above (suggested 3.0GHz) |
|
Memory Size |
512MB or above (suggested 1.0GHz) |
|
Display Card |
64M or above |
|
Supported OS |
Microsoft Windows XP/Vista/Windows7 |
|
Browser |
E 6.0, IE7.0 IE8.0 firefox2.0 firefox3.0 .Google |
