Product Details:
Payment & Shipping Terms:
|
High Light: | dome cctv camera,network security camera |
---|
Outdoor Waterproof Color IR D/N CCTV CCD Camera
Performace Specification:
Technical Specifications:
Hardware | Mega5-GH |
cpu | ARM9,32 bit RISC |
SoC | Hi3515 |
RAM | 128MB |
ROM | 16MB |
LAN | Realtek 10/100M BASE-TX |
Camera | |
Sensor | 1/2.8 type solid state Progressive Scan CCD |
Effctive pixels | 1920(H) x 1080(V) |
Total pixels | 2.3 megapixles |
Lens | 20X optical zoom F1.6(wide)~F3.5(tele), f=4.7~94mm, |
Iris | F1.6 ~F9 |
Horizontal angle | 55.2°(W)~2.9°(T) |
Min. illumination | 1.6Lux/0.04lux |
SNR | ≥50db |
Electronic shutter | 1/1to 1/10000 |
Interface | |
Voice talkback output | 1 channel,MIC port(optional) |
Audio output | 1channel,linear output(optional) |
Analog video output | Support |
Input alarm | 1 channel |
Output alarm | 1 channel |
Hard reset | Support |
Memory interface | Support image and video storage,SD2.0, |
Compression | |
Video compression | H.264 Main Profile@Level 3.0 / MJPEG selectable |
Max. image resolution | Preferred stream:1920*1080, 25fps |
Alternated stream:640x480 | |
Video compressed code | 32Kbps~16Mbps setable |
OSD title | Support channel name, date and video information overlay; OSD position adjustable |
Audio compression | G.726/G.711A/G.711U |
Image | |
Mask setting | Max 4 Zones selectable |
Dual stream | Support |
Email alarm | Support |
Protocol | TCP/IP,UDP,RTP,RTSP,RTCP,HTTP,DNS,DDNS,DHCP,FTP,NTP,PPPOE,SMTP,UPNP |
ONVIF protocol | Support |
Motion detection | Support intelligent mobile phone with Windows Mobile 6,Symbian V3/5 version , iPhone and Android system |
Dome | |
Horizontal rotation range | 360° infinit contionuous rotation |
Tilt rotation range | 0°~90° auto flip 180° |
Pan manual operation speed | 0.1~250°/S |
Tilt manual operation speed | 0.1~200°/S |
Preset running speed | 120°/S |
Preset accuracy | ±0.20° |
Preset number | 128 |
Power off memory | Power off momory function, auto wakeup tour function |
Working temperature | -30°C~60°C |
Working humidity | 0% - 90% |
Power supply | 24VAC 3A 60Hz/50Hz |
Comsuption | Max.40W |
IR parameters | |
Number of 20 lamps | 6 |
Number of 30(high power) | 1 |
Lamp working manner | 1-5X short range lighting;6-11X medium range lighting;12-20long distance lighting |
IR distance | 150m |
Flashlight | Have |
Related validation | IP66,CE,FCC,RoHs |
