4 channel NVR Network digital Video Recorder H.264 with VGA/HDMI/P2P/Alarm/ONVIF
Quick Detail:
1. Model Number: NVR-3504
2. Brand Name: ZHIBOSEN
3. Type: NVR Network Video Recorder
4. Channel: 4 channel
5. RJ45 connect: 1 pcs
6. VGA connect: 1 pcs
7. HDMI connect: 1 pcs
8. USB connect: 2 pcs USB 2.0
9. HDD: Support 1pcs 4TB SATA HDD
9. Place of Origin: Guangdong China
10. Gross Weight: 2.2kg
11. Package Size: 255x225x45mm
Description:
Applications:
Applies to family, community, roads, warehouses, underground parking, bar, schools, factories, companies, police stations, banks and other institutions.
Specifications :
Operating system | Embedded LINUX operating system |
Encoding | H.264 Main Profile |
Dual-stream | Each channel can be set, range (128k ~ 12Mbps) |
Frame Rate | NTSC System : 30 frames / sec ; PAL System : 25 frames / sec. |
Resolution | 1080P (1920 × 1080) / 720P (1280 × 720) / 960P (1280x960) |
ISP Parameters | Direct control of the front end of the IPC ISP parameters ( iris , gain, white balance , 3D noise reduction, wide dynamic range , image mirroring, day and night , etc. ) |
Image Playback Quality | 4-way simultaneous playback resolution of the main stream |
Video mode | Manual / Timer / Motion detection / alarm sensor |
Backup | U disk , SD card , USB mobile hard disk , USB burner , network storage and backup |
Operation | Mouse |
Recordings are saved | Local hard drive, remote video |
Audio Output | RCAx1 |
Video Output | (VGAx1, HDMIx1, 1080P) CVBSx1 (D1) |
Network Interface | 16 10/100/1000M adaptive ; 10/100M adaptive 4/ 8 |
RS485 interface | Duplex standard 485 interface, support for multiple PTZ protocols , supports keyboard control PTZ joystick |
USB Interface | Two USB 2.0 ports ( 1 front panel , rear tailgate 1 ) |
Alarm Input | Not supported |
Alarm Output | No |
Wireless Interface | 3G, WIFI ( when you need to customize ) |
Maximum capacity | Each interface supports a maximum capacity of 4TB hard drive |
Remote monitoring | Support IE browser , smartphones , CMS access |
Power supply | DC12V/4.5A |
Power Consumption | ≤ 30W ( bare metal ) |
Operating Temperature | -10degree ~ +60 degree |
Humidity | 10% -90 % |
Size | Machine : 320mm × 250mm × 50mm, |
With packaging : 370mm × 370mm × 100mm | |
Weight (without HDD) | Weight : 1.4Kg; including packaging : 2.4Kg |
