16 Channel 720P H.264 NVR Network Video Recorder , 720P (1280 × 720) 30 frames / sec
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| High Light: | network digital video recorder,network video recorder |
||
|---|---|---|---|
16 Channel 720P H.264 NVR Network Video Recorder , 720P (1280 × 720) 30 frames / sec
Quick Detail:
1. Model Number: NVR-5308
2. Brand Name: ZHIBOSEN
3. Type: NVR Network Video Recorder
4. Channel: 16 channel
5. RJ45 connect: 1 pcs
6. VGA connect: 1 pcs
7. HDMI connect: 1 pcs
8. USB connect: 2 pcs USB 2.0
9. HDD: Support 2pcs 4TB SATA HDD
9. Place of Origin: Guangdong China
10. Gross Weight: 5kg
11. Package Size: 535x465x165mm
Description:
1. H.264 Main Profile compression standard , a higher compression ratio , better image quality.
2. Can be connected to network cameras, network video servers and network fastball ; support multiple versions Onvif agreement.
3. Compatible with the mainstream market brand network cameras.
4. VGA, HDMI synchronous output , maximum resolution up to 1080P
5. The preview screen can be freely exchanged , image position changes , physical address change, to facilitate construction ;
6. Tree menu structure , operation more convenient ;
7. 2 interface colors to choose from ( an elegant black and sky blue )
8. Mouse roller to achieve 15 times digital zoom , enlarge the image can easily drag ( preview , playback , remote access ) ;
9. The network can be controlled by mouse roller ball machine zoom to achieve fast positioning of the target
10. Instant capture , that catch -per-view ; and the establishment of an independent regional shot saved on the hard disk ;
11. Video playback time column shows the type of video color representation , quick and easy retrieval of video data ;
12. Video backup can occur based on the time and length of time to backup, backup can be accurate to the second ( backup precise ) ;
13. U-disk backup files can be played back directly on the host queries , provide more convenience to playback the backup file ;
14. Equipped with 3G, WIF wireless connectivity ;
15. Standard resolution , according to the display device to adjust the resolution , give full play to the effect of the display image ;
16. The wording of the order of the hard disk , the track began to write data from zero encountered bad sectors automatically skipped to avoid bad sectors sectors Ben collapse after file system , improve the efficiency of disk usage .
Applications:
Applies to family, community, roads, warehouses, underground parking, bar, schools, factories, companies, police stations, banks and other institutions.
Specifications :
| Operating system | Embedded LINUX operating system |
| Image encoding control | The picture quality can be adjusted, variable stream and limited optional stream |
| Dual-stream | Each channel can be set |
| Video Standard | NTSC system: 1080P (1920 × 1080) 30 frames / sec; 720P (1280 × 720) 30 frames / sec, PAL system: 1080P (1920 × 1080) 25 frames / sec; 720P (1280 × 720) 25 frames / sec. |
| Monitor image quality | 1080P (1920 × 1080) / 720P (1280 × 720) |
| Image motion detection | Each screen can detect multiple detection area, sensitivity can be set to 6 |
| Image Playback Quality | 4-way simultaneous playback any 1080P/720P |
| Regional block set | Each supports four regional block |
| Recording mode | Support manual, automatic, dynamic monitoring, alarm triggered recording mode |
| Backup | Support hard disk, U disk, USB mobile hard disk, USB burner, network storage and backup |
| Operation | Mouse, remote control, front panel buttons |
| Log on locally | User name and password |
| Recordings are saved | Local hard drive, network |
| Audio Input | 4/8/12/16 road network audio input |
| Video Output | 1 channel VGA +1 HDMI Road |
| Network Interface | 1 RJ45, 10M/100M/1000M adaptive Ethernet port |
| RS485 interface | Duplex standard 485 interface, support 19 kinds of PTZ protocol |
| USB Interface | 3 USB 2.0 ports (1 front panel, rear tailgate 2) |
| Alarm Input | 16 |
| Alarm Output | 4 |
| Wireless Interface | 3G, WIFI |
| Maximum capacity | Each interface supports a maximum capacity of 3TB hard drive |
| Phone monitoring | Support (iPhone, Windows Mobile, BlackBerry, Symbian, |
| Android) smart phones | |
| Power supply | 2 bits DC12V/5A, 6-bay is ATX110-220V 250W 50-60Hz |
| Power Consumption | ≤ 30W (without hard disk) |
| Operating Temperature | -10degree ~ +60 degree |
| Humidity | 10% -90% |
| Size | Machine: 440mm × 370mm × 68mm, |
| With packaging: 535mm × 465mm × 165mm | |
| Weight (without HDD) | NW: 4.5Kg; including packaging: 5Kg |
Competitive advantages:
good price, reliable quality, guarantee of delivery, best services
