IP66 Waterproof PTZ High Speed Dome Camera

Model

HE-620-S18

HE-620-SN18

HE-620-SN26

HE-620-SN36

Image sensor

1/4" Sony Super HAD CCD

1/4" Sony Exview HAD CCD

1/4" Sony Exview HAD CCD

1/4" Sony Exview HAD CCD

Effective pixels

P:752(H)×582(V)
N:768(H)×494(V)

P:752(H)×582(V)

N:768(H)×494(V)

P:752(H)×582(V)

N:768(H)×494(V)

P:752(H)×582(V)

N:768(H)×494(V)

Horizontal resolution

480TVL

480TVL (Color)
520TVL (B/W)

480TVL (Color)
520TVL (B/W)

540TVL(Color)
570TVL(B/W)

Zoom

18x optical zoom
12x digital zoom

18x optical zoom
12x digital zoom

26x optical zoom
12x digital zoom

36xoptical zoom
12xdigital zoom

Lens

4.1~73.8mm

4.1~73.8mm

3.5-91mm

3.4-122.4mm

Minimum illumination

0.1 Lux

0.01 Lux

0.01 Lux

0.01 Lux

Signal system

PAL/NTSC

Decoder

Built-in

Pan/Tile range

Pan: 360° continuous, Tilt: -5°~185° (Auto Flip)

Pan/Tile preset speed

Pan: 400°/s, Tilt: 400°/s

Pan/Tile manual speed

Pan: 0.2°~200°/s, Tilt: 0.2°~180°/s

Number of preset

256 presets (title can be set up, can set the time at each presetting position)

Cruising scan

6 lines, each line support 18 presets position

Pattern scan

4 lines, each line can record 5-500 minutes

Auto scan

1 line

Privacy masking zones

8 zones

Alarm input/output

6 alarm input, 2 alarm output

Electronic shutter speed

PAL:1/50-1/10,000s
NTSC:1/60-1/10,000S

RS-485 protocols

Pelco-P, Pelco-D, HIKVISION, SAMSUNG

Baud rate

2400/4800/9600

Protection grade

IP66, Built-in surge and lightning strike protector, heat abstractor and temperature control device

Sync. System

Internal

White balance

Auto /Manual

AGC

Auto/Manual

S/N ratio

More than 50dB

BLC

ON/OFF

Power supply

AC24±4V, 50Hz

Power consumption

50W

Working temperature

-40°C - +60°C

Dimension

Φ217×268mm

Weight

5.1 kg
