Vandalproof Dome IP Network Video Security Cameras Used Indoor

Model

EPC-HS208DP2

Onvif IR Speed Dome IP Network Camera

Image Sensor

1/3" Progressive Scan CCD

Scan System

1:1 Progressive

Effective Pixels

1296(H)x966(V) /1280(H)x720(V) /1280(H)x960(V)

Minimum Illumination

1.8Lux@F1.6(Color); 0.02Lux@F1.6 (B/W)

IR Distance

30M-120M

White Balance

ATW/Manual

Backlight Compensation

ON/OFF

Day/Night

Auto

Lens

18 x Optical ZOOM(4.7-84.6mm); F=1.6(W)~F=2.8(T)

Horizontal Viewing Angle

55.2°(wide) - 3.2°(tele)

Pan&Tilt

Preset Speed: Pan: 0°-350°/sec, Tilt speed: 0.°-90°/sec

Manual Control Speed: 0.1°-300°/sec, Tilt speed: 0.5°-90°/sec

Preset and cruise

255 preset position and 6 cruise position

Protection Classification

IP66

Frame Rate

1~30fps

Video /Audio

Video Compression

H.264/MJPEG

Frame Rate

1-30fps

Resolution

720P,D1, Half D1

Video Stream

H.264, Bit-rate Range(1Mbps-16Mbps)

Image Settings

Brightness, contrast, saturation, hue, Exposal control, AES(1/2 to 1/4,000 sec.), AGC, AWB, BLC, Privacy mask, Motion Detection;

Audio Compression

G.711

Audio Stream

Two-way audio, broadcast

Network

Ethernet

10/100 Mbps Ethernet RJ-45 port

Protocols

TCP/IP,HTTP,DHCP,DNS,RTP/RTCP,PPPOE,FTP,SMTP,NTP,SNMP

Security

Multi-level user access with password protection

System Integration

IP Camera Hardware

High performance CPU, Flash 8M, DRAM 128M, OS Built-in Linux

View System requirement

OS: Microsoft Windows 2000/2003/XP/Vista/Win7

Browser: Internet Explorer 6.0 or above

Management Software

FREE software for monitoring and recording, support 1-100 channels

WEB Server

Support WEB browser, remote config/update, replay, record

Alarm port

One D/I and one D/O for external sensor and alarm

Alarm trigger

Video lost, motion detection, external input

Alarm Events

File upload via FTP, Email; Notification via Email, and TCP; External output activation; Local recording;

General

Connectors

RJ-45 10BASE-T/100BASE-TX, DC Power, Terminal block for 1 alarm input, 1output; Mic input headphone output, RS485 (PTZ), Alarm I/O

Operation Conditions

Temperature:-35℃     -60℃; Humidity:<90%RH

Voltage

AC12V/5A

Consumption

≤50W

Weight

3.8 KG

Product Dimension (mm)

Φ228×341 mm
