High Speed Dome IP Camera
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| High Light: | cctv speed dome camera,varifocal dome camera |
||
|---|---|---|---|
High Speed Dome IP Camera
1/3.-type HAD CCD 650 TVlines 18x optical zoom NTSC / PAL Effio-p Zoom Camera EFFIP-P
18X EFFIO-P
1/3" Sony 960H Exview CCD
Auto ICR(IR Cut Filter Removal)Mode
216 zoom ratio(Optional 18X,Digital
High Resolution:700TV lines
Ture-WDR,3D-DNR(Noise Reduction)
Privacy Zone Masking
E-Flip,picture Freeze,Sense-up
Effio-p Zoom Camera specificatios:
| CAMERA | HKZ-183AP | |
| IMAGE SENSOR |
Type | 1/3.-type HAD CCD |
| Number of effective Pixel |
NTSC : 480K, PAL : 570K |
|
| Resolution | 650 TVlines | |
| Lens | 18x optical zoom | |
| f=4.7mm(wide) to 84.6mm(tele) | ||
| F1.6 to 2.7 | ||
| Digital zoom | 12x(216x with optical zoom) | |
| Angle of view | 68.5(wide end) to 4.2(tele end) | |
| Minimum Object distance | 100mm(wide end) to 1000mm(tele end) (Default:1000mm) | |
| Sync system | Internal | |
| Minimumillumination(50%) | 0.5lx(F1.6, ICR on) | |
| S/N ratio | More than 50dB | |
| Viseo output | VBS(1Vp-p) | |
| Camera control interface | VISCA(CMOS 5V level), PELCO-D, PELCO-C, LG. Baud rate:9.6Kbps, 19.2Kbps, 38.4Kbps, Stop bit:1bit | |
| Electronic shutter speed | 1/1 to 1/10,000s, total22steps | |
| White balance | Auto, ATW, CRS, Indoor, Outdoor,One-push, Manual | |
| Gain | Auto/Manual(-3dB to +28, +2dB step/total 16 steps) Max. Gain Limit(+6dB to +28dB, +2dB step/ total 12 steps) |
|
| AE control | Auto, Manual, Priority mode( shutter & Iris Priority), Bright, EV compensation, Slow AE |
|
| Focusing system | Auto, One-push AF, Manual, IntervalAF, Zoom Trigger AF | |
| Backlight compensation | Yes | |
| Aperture control | 16 steps | |
| Image stabillzation | Yes | |
| Auto ICR | Yes | |
| Spherical privacy zone masking |
Yes | |
| Noise reduction | Yes(On/Off) (Level 5 to 1) | |
| Picture effects | Yes(E-FLIP,Nega Art, Black & White, Mirror Image) | |
| Picture freeze | Yes | |
| WDR | Yes(True-WDR) | |
| Slow shutter | Yes | |
| Title display | Yes(19 characters/line) | |
| Camera mode display | Yes | |
| General | ||
| Storage temperature | -20C to +60C | |
| Storage humidity | 20% to 95% | |
| Operating temperature | -5C to 60C | |
| Operating humidity | 20% to 80% | |
| Power requirements | 6.0V to 12.0V DC | |
| Power consumption | 3.8W(zoom/focus active) | |
| Mass | 200g | |
| Dimensions(WxHxD) | 50x57.6x76.7 mm | |
